The default motor of the kit is the above one rather the cassette motor. If you want the cassette motor, you need to contact us and pay extra 10USD.Cassette mtor could just be delivered from China. The stock in Poland/Belgium warehouse has NO cassette motor. The kit also doesn’t include the freewheel.If you need a cassette mtor.I suggest you choose the stock in Poland/Belgium warehouse and buy a freewheel that with screw thread.
BULU Service :
1,If you need torque arm, it only need extra 7usd. If you need extra disc brake rotor 16mm, only 3usd. If you need extra 7 speed 11-32T freewheel, it is only 15usd. If you need to change to Brake Sensor,It’s one piece,not one pair.If you need one pair,need extra 5usd.They only can be shipped with motor wheel in China. From oversea warehouse .Its not optional and can’t change parts.
2,We’ll declare about $110 pic to avoid that you pay too much taxes except Brazil and strict Customs Countries. Please kindly contact us firstly if the customs ask you to provide documents like PI to clear customs.
3,In the following countries, your tax will be paied by us if you buy DDP shipping service together with motor kit.the United Kingdom Germany Belgium Luxembourg Netherlands Slovenia France Poland Austria Czech Republic Denmark Hungary Slovakia Lithuania Spain Sweden Latvia Italy Portugal Estonia Croatia Finland Romania Russia.
1.Wheel size optional : 20 inch , 26 inch , 27.5 inch , 28 inch ,700C (750W Mortor does not have the choice of Front motor, and there is no choice of 20-inch wheels.)
2.Hub motor optional : Front motor , Rear motor , Rear cassette motor(+10 USD) (1500W Mortor does not have the choice of Cassette motor.)
3.Ebrake（can upgrade） : MS-2R Brake Sensor （1 Piece）/ For Hydraulic disc brake or you want to keep your own brake. Its convenient.Please leave us a message when you place the order.
4.Front 500W / Front 750W / 1000W 1500W can’t do 2 time cross
5.250W 350W : P19D Rim (For tire 1.5-1.95)
500W 750W 1000W 1500W : P25D Rim (For tire 1.75-2.125)
1500W(Special) : MTX-P30D Rim Only for MTB Bike (For tire 2.5-3.0)
Please check the size of the rims carefully before you order it.Or If you have special requirements, please contact us in time.
750W/1000W/1500W Motor does not have the choice of Front motor.
Motor Wheel Details
48V Motor wheel Full No-load Speed:
48V 500W 【Gear】about 32-38km/h 310 RPM 50NM
48V 750W 【Gear】 about 42-45km/h 390 RPM 60NM
48V 1000W 【Gearless】about 38-42km/h 385 RPM 60NM
48V 1500W 【Gearless】about 45-55km/h 450 RPM 70NM
Rim: Double-wall Aluminium Alloy Rim / 25mm inner width
36V Motor wheel Full No-load Speed:
36V 250W【Gear】about 25-28km/h 270 RPM 35NM
36V 500W【Gear】about 32-38km/h 270 RPM 40NM
Rim: Double-wall Aluminium Alloy Rim / 19mm inner width
Our motors Advantages :
Rotor Height: 24mm, More Powerful
Magnet Height: 24mm, More Powerful
Lamination/Silicon Steel Sheet: 0.35mm, Material 270 Higher Motor Efficiency
Nylon gear: 12mm, Better Quality Material, Higher torque, 20% Longer Using Life
Bearing: C&U Better quality, motor more quiet
Motor Axle: Salt Mist Axle, Anti-rust
Speed sensor: Integrated
6 mosfet controller（36V14A ）
Fit for: 36V 250W motor wheel
Max current: 14±1A
9 mosfet controller（36V/48V 22A ）
Fit for: 36V/48V 500W 750W motor wheel
Max current: 22±1A
Fit for: 48V 1000W/ 1500W motor wheel
Max current: 30±1A / 35±1A
